G-NiCr28W (EN 2.4879) Nickel-Chromium Alloy Casting Material

Nickel-Chromium Alloy

Introduction

G-NiCr28W is a nickel-chromium alloy grade covered by EN 10295. Typical applications include heat-resistant cast components.

Field	Value
Designation	G-NiCr28W (EN 2.4879)
Material Type	Nickel Alloy
Sub Type	Nickel-Chromium Alloy
Product Form	casting

Manufacturing Process

Sand Casting
Investment Casting

Equivalent Materials

N/A

Similar Materials

N/A

Reference Standards

Standard	Standard Title	Edition	Specification	Identifier
EN 10295	Heat resistant steel castings	2002	G-NiCr28W	—

Related Casting Products

Physical Properties

Property	Value / Unit	Note	Source
Density	8.2 kg/dm³		EN 10295
Specific Heat	500 J/(kg·K)	Temperature: 20 °C	EN 10295
Thermal Conductivity	11 W/(m·K)	Temperature: 20 °C	EN 10295
Thermal Conductivity	11.3 W/(m·K)	Temperature: 100 °C	EN 10295
Thermal Conductivity	30.6 W/(m·K)	Temperature: 800 °C	EN 10295
Thermal Conductivity	36.1 W/(m·K)	Temperature: 1000 °C	EN 10295
Thermal Expansion	14.4 ×10⁻⁶/K	Temperature range: 20–400 °C	EN 10295
Thermal Expansion	15.7 ×10⁻⁶/K	Temperature range: 20–800 °C	EN 10295
Thermal Expansion	16.3 ×10⁻⁶/K	Temperature range: 20–1000 °C	EN 10295

Chemical Composition

Element	EN 10295Edition 2002 · wt.%Cast analysis
C	0.35–0.55
Si	1.00–2.00
Mn	≤ 1.50
P	≤ 0.040
S	≤ 0.030
Cr	27.00–30.00
Ni	47.00–50.00
Fe	balance
Mo	≤ 0.50
Co	≤ 1.00^[1]
W	4.00–6.00
Nb	≤ 0.60^[1]
Cu	≤ 0.25^[1]
V	≤ 0.12^[1]

Notes

EN 10295 · Edition 2002

[1] Co/Nb/Cu/V: Unless otherwise agreed: limit for element unspecified in; no intentional addition except for finishing the heat.

Heat Treatment

EN 10295–2002

N/A

Mechanical Properties

Core Mechanical Properties

EN 10295 — 2002 · Table 2 — Normative

Property	As cast / no heat treatment
Yield Strength	≥ 240 MPa
Tensile Strength	≥ 440 MPa
Elongation	≥ 3 %

Notes

Room temperature

Additional Mechanical Properties

Creep & Stress-Rupture Properties

Property	Value / unit	Temperature / conditions	Nature	Source / edition	Notes
σ1% — mean stress for 1% elongation	70 MPa	Temperature: 700 °C; Load time: 10000 h	Informative	EN 10295–2002 · EN 10295:2002, Annex B, Table B.1 (informative)	Mean values; ±20% scatter band; information only, not acceptance requirements; Mean creep values from a scatter band of ±20%; information only.
σr — mean rupture stress	80 MPa	Temperature: 800 °C; Load time: 1000 h	Informative	EN 10295–2002 · EN 10295:2002, Annex B, Table B.1 (informative)	Mean values; ±20% scatter band; information only, not acceptance requirements; Mean creep values from a scatter band of ±20%; information only.
σ1% — mean stress for 1% elongation	41 MPa	Temperature: 800 °C; Load time: 10000 h	Informative	EN 10295–2002 · EN 10295:2002, Annex B, Table B.1 (informative)	Mean values; ±20% scatter band; information only, not acceptance requirements; Mean creep values from a scatter band of ±20%; information only.
σr — mean rupture stress	45 MPa	Temperature: 900 °C; Load time: 1000 h	Informative	EN 10295–2002 · EN 10295:2002, Annex B, Table B.1 (informative)	Mean values; ±20% scatter band; information only, not acceptance requirements; Mean creep values from a scatter band of ±20%; information only.
σ1% — mean stress for 1% elongation	22 MPa	Temperature: 900 °C; Load time: 10000 h	Informative	EN 10295–2002 · EN 10295:2002, Annex B, Table B.1 (informative)	Mean values; ±20% scatter band; information only, not acceptance requirements; Mean creep values from a scatter band of ±20%; information only.
σr — mean rupture stress	23 MPa	Temperature: 1000 °C; Load time: 1000 h	Informative	EN 10295–2002 · EN 10295:2002, Annex B, Table B.1 (informative)	Mean values; ±20% scatter band; information only, not acceptance requirements; Mean creep values from a scatter band of ±20%; information only.
σ1% — mean stress for 1% elongation	10 MPa	Temperature: 1000 °C; Load time: 10000 h	Informative	EN 10295–2002 · EN 10295:2002, Annex B, Table B.1 (informative)	Mean values; ±20% scatter band; information only, not acceptance requirements; Mean creep values from a scatter band of ±20%; information only.
σr — mean rupture stress	10 MPa	Temperature: 1100 °C; Load time: 1000 h	Informative	EN 10295–2002 · EN 10295:2002, Annex B, Table B.1 (informative)	Mean values; ±20% scatter band; information only, not acceptance requirements; Mean creep values from a scatter band of ±20%; information only.
σ1% — mean stress for 1% elongation	4 MPa	Temperature: 1100 °C; Load time: 10000 h	Informative	EN 10295–2002 · EN 10295:2002, Annex B, Table B.1 (informative)	Mean values; ±20% scatter band; information only, not acceptance requirements; Mean creep values from a scatter band of ±20%; information only.

Welding Conditions

N/A

Applications

Nickel-chromium alloy EN 10295 G-NiCr28W is used for heat-resistant cast components. EN 10295:2002 gives an informative maximum use temperature in air of 1150 °C, based on oxidation resistance in clean natural air. These figures are not guaranteed continuous or intermittent service temperatures, or allowable temperatures under load; other atmospheres require separate assessment.

Other cast components used in this material family include furnace fixtures, support elements and burner-assembly components. These applications include industrial heating and heat-treatment equipment. Atmosphere, loading, direct flame exposure, cyclic operation and process deposits must be considered separately from an in-air reference temperature.
