Introduction
G12MoCrV5-2 (EN 1.7720) is a low-alloy steel casting grade specified in EN 10213. The standard defines delivery conditions and engineering requirements for pressure-containing components. Casting process options include Investment Casting, Shell Molding Casting and Sand Casting, subject to the applicable specification and component requirements.
| Field | Value |
|---|---|
| Designation | G12MoCrV5-2 (EN 1.7720) |
| Material Type | Alloy Steel |
| Sub Type | Low-Alloy Steel |
| Product Form | casting |
Manufacturing Process
Investment Casting
Shell Molding Casting
Sand Casting
Equivalent Grades
N/A
Similar Materials
N/A
Reference Standards
| Standard | Standard Title | Edition | Specification | Identifier |
|---|---|---|---|---|
| EN 10213 | Steel castings for pressure purposes | 2007+A1:2016 | G12MoCrV5-2 | — |
Related Casting Products
Physical Properties
EN 10213–2007+A1:2016
| Property | Value | Note |
|---|---|---|
| Density | 7.85 kg/dm³ | Test at 20 °C |
| Specific Heat | 460 J/(kg·K) | Test at 20 °C |
| Magnetic Property | Magnetic |
Chemical Composition
| Element | EN 10213Edition 2007+A1:2016 · wt.%Cast analysis |
|---|---|
| C | 0.10–0.15 |
| Si | ≤ 0.45 |
| Mn | 0.40–0.70 |
| P | ≤ 0.030 |
| S | ≤ 0.020[1] |
| Cr | 0.30–0.50 |
| Ni | ≤ 0.40 |
| Mo | 0.40–0.60 |
| Cu | ≤ 0.30 |
| V | 0.22–0.30 |
Notes
EN 10213 · Edition 2007+A1:2016
[1] S: For ruling thickness < 28 mm, sulfur up to 0.030 wt.% is permitted.
Heat Treatment
EN 10213–2007+A1:2016 · +QT
Notes
EN 10213 · Edition 2007+A1:2016
[1] +QT: Treatment temperatures are given for information; required delivery condition is specified separately.
Mechanical Properties
| Property | EN 10213Edition 2007+A1:2016 |
|---|---|
| Yield Strength (Rp0.2) | ≥ 295 MPa[1] ≥ 264 MPa[2] ≥ 244 MPa[3] ≥ 230 MPa[4] ≥ 214 MPa[5] ≥ 194 MPa[6] ≥ 144 MPa[7] |
| Tensile Strength | 510–660 MPa[1] |
| Elongation | ≥ 17 %[1] |
| Impact Energy | ≥ 27 J[1] |
Notes
EN 10213 · Edition 2007+A1:2016
[1] Yield Strength (Rp0.2)/Tensile Strength/Elongation/Impact Energy: wall thickness ≤ 100 mm; Properties verified on test blocks of thickness up to 150 mm; applicability to casting wall thickness as stated. Larger governing thickness requires agreement.; Room temperature
[2] Yield Strength (Rp0.2): Test at 100 °C; Verification of elevated-temperature yield values is subject to agreement at enquiry and order.
[3] Yield Strength (Rp0.2): Test at 200 °C; Verification of elevated-temperature yield values is subject to agreement at enquiry and order.
[4] Yield Strength (Rp0.2): Test at 300 °C; Verification of elevated-temperature yield values is subject to agreement at enquiry and order.
[5] Yield Strength (Rp0.2): Test at 400 °C; Verification of elevated-temperature yield values is subject to agreement at enquiry and order.
[6] Yield Strength (Rp0.2): Test at 500 °C; Verification of elevated-temperature yield values is subject to agreement at enquiry and order.
[7] Yield Strength (Rp0.2): Test at 550 °C; Verification of elevated-temperature yield values is subject to agreement at enquiry and order.
Welding Conditions
EN 10213–2007+A1:2016
Notes
EN 10213 · Edition 2007+A1:2016
[1] Preheat: Production welding by the foundry; ferritic/martensitic guidance is informative.; Preheat temperature depends on casting geometry, thickness and climatic conditions.
[2] Interpass Temperature: Production welding by the foundry; ferritic/martensitic guidance is informative.
[3] Post-weld Heat Treatment: Production welding by the foundry; ferritic/martensitic guidance is informative.; In general, production welds are major when prepared cavity depth exceeds 40% of the wall thickness; minor weld corrosion conditions may require special agreement.
Applications
At the casting-family level, typical applications include valve bodies, pump casings and other pressure-containing components. Material selection should account for service temperature, loading and the specified delivery condition.
